TJ-NC70 |
| |
|
|
|
TECHNICAL DATA |
| Crimping
force |
500KN/50ton |
Crimping
range |
70mm |
| Max
Coupling size(inches) |
2" |
| Dies
opening |
30mm |
| Dies(set) |
STD-NC |
| Crimping
speed/crimp |
7mm/sec |
| Standard
voltage |
220/380volt 60hz 3ph |
| Motor
power |
3.7kw |
| Back
stopper |
included |
| Electric
pedal |
included |
| Marking/spacial
dies |
optional |
| Length |
1850mm |
| Width |
900mm |
| Height |
1500mm |
| Weight |
550kg |
|
| |
|
|
