TJ-OC75-50 |
| |
|
|
|
TECHNICAL DATA |
| Crimping
force |
85ton |
Crimping
range |
60mm |
| Max
hose size(inches) |
1 1/4" |
| Dies
opening |
20mm/55mm |
| Crimping
speed/close |
9.5mm/sec |
| /crimp |
9.5mm/sec |
| /open |
26mm/sec |
| Standard
voltage |
220/380volt 60hz 3ph |
| Motor
power |
5.5kw |
| Electric
pedal |
included |
| Marking/spacial
dies |
optional |
| Length |
950mm |
| Width |
850mm |
| Height |
1750mm |
| Weight |
1135kg |
|
| |
|
|
