TJ-OC50-35 |
| |
|
|
|
TECHNICAL DATA |
| Crimping
force |
50ton |
| Crimping
range Ø |
40mm |
| Max
hose size(inches) |
3/4" |
| Dies
opening Ø |
20mm/40mm |
| Crimping
speed/close |
37mm/sec |
| /crimp |
7mm/sec |
| /open |
81mm/sec |
| Standard
voltage |
220/380volt 60hz 3ph |
| Motor
power |
3.7kw |
| Electric
pedal |
included |
| Marking/spacial
dies |
optional |
| Length |
1620mm |
| Width |
800mm |
| Height |
1150mm |
| Weight |
1430kg |
|
| |
|
|
